*Discontinued* Jonard Tools – Modified Wire Wrapping Bit – 28 AWG

Fully compatible with any make or model of wire wrapping tools, this 3″ modified wire wrapping bit is perfect for wrapping 28 AWG wire around binding posts when used in conjunction with a wire wrapping tool.Provides one and a half turns of insulation per wire wrap, increasing the mechanical stability the wrapCompatible Wrap Sleeve Part : P3032 and P3032INSSpecificationsSleeve Part No.P3032 and P3032INS (sold separately)Wrap FunctionWrapWrap TypeModifiedWire Gauge28 AWG (0.32 mm)Maximum Insulation Diameter0.030″ (0.76 mm)Minimum Terminal Diagonal0.031″ (0.79 mm)Maximum Terminal Diagonal0.035″ (0.89 mm)Terminal Hole Depth0.75″ (19.05 mm)Terminal Hole Diameter0.036″ (0.91 mm)Effective Radius0.066″ (1.67 mm)Wrap Post Size0.025 (0.63 mm)Dimensions3.11 in x 0.23 in x 0.22 in (7.9 cm x 0.59 cm x 0.55 cm)Weight0.01 lb (3.632 g)UPC 811490013506 Downloads:Spec Sheet
