*Discontinued* Jonard Tools – 26 AWG Kynar Wire – Optional Finish – 100 ft

Typically used where flexibility, strength, and low weight is required, Kynar wire is ideally suited in wire wrap, power supply, medical, and aerospace applications. It is also commonly used for circuit board prototyping because of its lighter weight and smaller overall diameter. Additionally, Kynar insulation provides excellent mechanical properties over a large temperature range and is resistant to an extensive range of chemicals including most inorganic and organic acids, bases, alcohols, halogenated solvents, and aliphatic & aromatic hydrocarbons. These properties make Kynar wire an excellent choice when working in even the harshest environmental applications. This wire also features the following:OHFC (oxygen-free high conductivity) silver-plated copper conductor provides exceptional electrical conductivity and flexibilityKynar insulation provides high temperature resistance (up to 105°C) and excellent abrasion resistanceMeets or exceeds UL 1422 standardsSpecificationsWire Gauge26 AWG (0.40 mm)Insulation TypeKynarInsulation Thickness0.005″ (0.127 mm)Overall Diameter0.027″ (0.69 mm)MaterialSilver Plated Copper ConductorStandardsUL 1422VoltageNot RatedDimensions2.79 in x 2.79 in x 1.28 in (7.09 cm x 7.09 cm x 3.25 cm)Weight0.14 lb (63.56 g) Downloads:Spec Sheet
