Simplex – LR1011 – Mechanical Pushbutton Cylindrical Lever Set – 2¾” Backset – Optional Finish – RH/RHR

Simplex Mechanical Pushbutton Locks eliminate problems and costs associated with issuing, controlling, and collecting keys and cards. The Simplex L1000 Series provides exterior access by combination, while allowing free egress. Combination Only, No Key OverrideFeatures:Fully mechanical lock eliminates the material and labor expense of battery replacementsSingle access code—one easy-to-manage code for all usersLock is easily programmed via keypad without removing lock from the doorFactory-handed for Right Hand or Right Hand Reverse. Not field reversiblePushbutton AccessSpecifications: Construction:Heavy-duty cylindrical lock housing with cast front housing, unified trim plate, and fixed ADA-compliant leversLocking Device:Cylindrical ½” (13 mm) throw latch, floating face plate 2¾” (70 mm) backset (UL listed)Numeric Keypad:Vandal resistant, solid metal pushbuttonsHanding:Right Hand or Right Hand ReverseFinish:Antique Brass (05)Backset:2¾” (70 mm) backsetLatch:½” (13 mm) throw latch, floating face plate 2¾”Minimum Stile Recommended:5″ (127 mm)Strike:Standard strike plate; ASA strike plateDoor Preparation:Easily installs on wood or metal doors. ASA 161 door preparation with additional through holes.Door Thickness:1⅜” (35 mm) to 2¼” (57 mm)—Pre-assembled to accommodate 1⅝” (41 mm) to 2″ (51 mm) doorsAccessibility Standard:Americans with Disabilities Act (ADA)Durability:D.O.D. Compliant 5220.22M for supplemental access control; weather resistantFire Rating:3-hour UL/ULC fire rating for “A” label doorsWarranty:3 years manufacturer warrantyDownloads:Installation GuideSpec SheetReturn Policy: We do not accept returns on unsealed products. In order to return a defective item a support ticket is needed. To receive a ticket, please contact DORMA KABA directly at 1-800-849-8324 or visit their support page here. Once you have the ticket contact UHS Hardware for the return.
