Rosslare – GC01 – DigiTool Data Acquisition Reader – 3.6 VDC

The GC-01 DigiTool Data Acquisition Reader is a handheld iButton data reader. Use this Reader during a guard patrol tour to conveniently read and store information from iButton location tags and event wallets.The reader can store up to 8000 time stamped readings. Using the GC-02 DigiTool base unit, information from the reader can then be downloaded to a server computer running Rosslare’s GS-01 DigiTool Reports Lite software.Features:Low battery and memory full alerts by means of vibration, visual, and audio beepsThree modes of notification: 1. Built-in 360 LED array for increased visibility of valid iButton reads 2. Built-in vibrating motor for tactile read confirmation 3. Built-in buzzer for audio read confirmationHigh capacity rechargeable internal 1800 mAh Lithium-ion batteryHighly-rugged and waterproof (meets IP-68 level tests)9600 baud speed uploading/ downloading speedSpecifications:ConstructionPolycarbonate and stainless steel housingOperating Voltage3.0–3.6 VDCInput CurrentStandby: 6 µAMax Input Current21 µAUploading/Downloading Speed9600 baud speedNumber of ReadsStores up to 8000 reads and time stampsBatteryInternal Lithium-Ion 1800 mAh rechargeable battery for six month use or 300,000 readingsBattery Charging TimeBattery charges in three hours from empty to fullBuzz Sounder IndicationInternal sounder for audio verificationLED IndicationFour ultra-bright LEDs visual read validation360 Degree LED viewing angle light-pipeData Read Speed0.1 seconds per readInternational Safety and EMCComplies with International Safety and Emissions RegulationsOperating EnvironmentSuitable for outdoor use (IP68 rated)Dimensions175 x 33 mm (6.9 x 1.3 in.)Manufacturer Warranty2-Year Limited WarrantyDownloads:Installation InstructionsData Sheet
