Overview:
E-flite’s 30-Amp Pro SB brushless ESC offers up to 30 amps of continuous current with proper airflow and a peak of 35A. It drives up to 5 analog or 4 digital sub-micro servos with the BEC on any recommended input voltage. This brushless ESC includes programmable motor braking, soft start for helis and planes, timing, throttle input range and low-voltage cutoff. It also features auto motor shutdown in case of lost signal or interference. The safe power-arm mode prevents accidental starts.
Key Features:
- Up to 30A continuous current with proper airflow, with 35A peak
- 5V switch-mode BEC circuit capable of 700mAh continuous current on any recommended input voltage
- Drives up to 5 analog or 4 digital sub-micro servos with the BEC
- 3S-4S Li-Po or 9- to 12-cell Ni-MH/Ni-Cd input voltage
- Programmable motor braking
- Safe power-arm mode prevents accidental starts
- Programmable low voltage cut-off with settings for 3S Li-Po (9.2V), 4S Li-Po (12V) or 74% of battery starting voltage
- Programmable soft start for helis and airplanes
- Auto motor shutdown if signal is lost or there is interference
- Programmable timing – 5 user selectable ranges for use with a larger variety of brushless motors
- Heli mode for starting the motor with a low speed ratio
- Optional RS232 Serial Link available for programming (EFLARS232)
- Pre-wired connectors-E-flite EC3 connectors on battery input and 3.5mm female gold bullets on motor output leads
